900# Flange Body Dimensions
| NPS | O Flange OD | tf Flange Thickness | X Hub Dia. | Y Hub Length | B11 Pipe Side Bore Dia | B13 Face Side Bore Dia | D Depth of Socket |
|---|---|---|---|---|---|---|---|
| 1/2 | 120 | 22.3 | 38 | 32 | 22.2 | BY P | 10 |
| 3/4 | 130 | 25.4 | 44 | 35 | 27.7 | BY P | 11 |
| 1 | 150 | 28.6 | 52 | 41 | 34.5 | BY P | 13 |
| 1-1/4 | 160 | 28.6 | 64 | 41 | 43.2 | BY P | 14 |
| 1-1/2 | 180 | 31.8 | 70 | 44 | 49.5 | BY P | 16 |
| 2 | 215 | 38.1 | 105 | 57 | 61.9 | BY P | 17 |
| 2-1/2 | 245 | 41.3 | 124 | 64 | 74.6 | BY P | 19 |
900# Bolts Template
| NPS | BCD Bolt Circle Dia. | BHD Bolt Hole Dia | BOLTS Number of Bolts | BD Dia. Of Bolt | SBL RF Stud Bolt Length (RF) | SBL RJ Stud Bolt Length (RJ) | MBL RF Machine Bolt Length (RF) |
|---|---|---|---|---|---|---|---|
| 1/2 | 82.6 | 7/8 | 4 | 3/4 | 110 | 100 | 110 |
| 3/4 | 88.9 | 7/8 | 4 | 3/4 | 115 | 110 | 115 |
| 1 | 101.6 | 1 | 4 | 7/8 | 125 | 120 | 125 |
| 1-1/4 | 111.1 | 1 | 4 | 7/8 | 125 | 120 | 125 |
| 1-1/2 | 123.8 | 1-1/8 | 4 | 1 | 140 | 135 | 140 |
| 2 | 165.1 | 1 | 8 | 7/8 | 145 | 140 | 145 |
| 2-1/2 | 190.5 | 1-1/8 | 8 | 1 | 160 | 150 | 160 |
General Notes
Dimensions are in millimeters, except for diameters of bolts and bolt holes, which are in inch units.
